Electric Tailgate System
Reliable at Extreme Low Temperatures
Description
Reviews
Introduction
As one of the leading aftermarket auto parts manufacturers in China with over eight years of experience specializes in producing electric tailgate systems. We provide a comprehensive selection of strut sizes and a variety of electric suction locks, all of which are compatible with more than 200 car models.
Key Features
- Offers five distinct lock head options, compatible with over 200 different car models.
- Adapts to varying tailgate weights and travel distances across different car models by utilizing springs of different lengths and strengths, ensuring a perfect fit for every electric tailgate.
- Functions reliably under extreme temperatures from -40 to 80 degrees Celsius.
- Features an easy installation process that requires no replacement of original components.
- Provides quality assurance with a one-year warranty.
Specification
| Items | Performance |
|---|---|
| Load level 1, half-lock | >4500N |
| Load level 1, full-lock | >11000N |
| Load level 2, half-lock | >4500N |
| Load level 2, full-lock | >9000N |
| Load level 3 | >9000N |
| Corrosion resistance | >240 H |
| Operating temperature | -40°C to 80°C |
| Operating voltage | 9 VDC to 16 VDC |
| Durability | 40,000 slam cycles |
| Overtravel | 4 mm |
| Holding force | >500 N @12V Ambient(Room temp) |
| Compatible latch diameters | 7.5/10.5 mm |
| Electric opening time | <1ms |
| Electric closing time | <2s |
| Operating current | <7A @16V Ambient(室温) |
| Switch protection level | IP67 |
